use fastlane to deploy android app

frontend/README.md

@@ -1,6 +1,6 @@
 # Frontend

-This is the frontend of the project. It is a Flutter application that is designed to run on both Android and iOS devices. The frontend is responsible for displaying the user interface and handling user input. It communicates with the backend to retrieve and send data.
+The frontend of this project is a Flutter application designed to run on both Android and iOS devices (and possibly as a PWA). The frontend is responsible for displaying the user interface and handling user input. It communicates with the backend via a REST-api to retrieve and send data.


 ## Getting Started
@@ -15,3 +15,16 @@ Once you have the Flutter SDK installed, you can locally install the dependencie
 ```bash
 flutter pub get
 ```
+
+## Deployment (using fastlane)
+The application is deployed to the Google Play Store and the Apple App Store using fastlane:
+
+[https://docs.fastlane.tools/](https://docs.fastlane.tools/)
+
+Fastlane is installed as a Ruby gem. Since the bundler-gemfile is scoped to a single directory, a gemfile is included in both the `android` and `ios` directories. Once installed, the usage is
+```bash
+cd frontend/android # or ios
+bundle install
+bundle exec fastlane <lane>
+```
+This is reused in the CI/CD pipeline to automate the deployment process.

frontend/android/.gitignore

@@ -12,3 +12,6 @@ GeneratedPluginRegistrant.java
 key.properties
 **/*.keystore
 **/*.jks
+
+# Fastlane google cloud access
+google-key.json

frontend/android/Gemfile

@@ -0,0 +1,3 @@
+source "https://rubygems.org"
+
+gem "fastlane"

frontend/android/Gemfile.lock

@@ -0,0 +1,220 @@
+GEM
+  remote: https://rubygems.org/
+  specs:
+    CFPropertyList (3.0.7)
+      base64
+      nkf
+      rexml
+    addressable (2.8.7)
+      public_suffix (>= 2.0.2, < 7.0)
+    artifactory (3.0.17)
+    atomos (0.1.3)
+    aws-eventstream (1.3.0)
+    aws-partitions (1.970.0)
+    aws-sdk-core (3.202.2)
+      aws-eventstream (~> 1, >= 1.3.0)
+      aws-partitions (~> 1, >= 1.651.0)
+      aws-sigv4 (~> 1.9)
+      jmespath (~> 1, >= 1.6.1)
+    aws-sdk-kms (1.88.0)
+      aws-sdk-core (~> 3, >= 3.201.0)
+      aws-sigv4 (~> 1.5)
+    aws-sdk-s3 (1.159.0)
+      aws-sdk-core (~> 3, >= 3.201.0)
+      aws-sdk-kms (~> 1)
+      aws-sigv4 (~> 1.5)
+    aws-sigv4 (1.9.1)
+      aws-eventstream (~> 1, >= 1.0.2)
+    babosa (1.0.4)
+    base64 (0.2.0)
+    claide (1.1.0)
+    colored (1.2)
+    colored2 (3.1.2)
+    commander (4.6.0)
+      highline (~> 2.0.0)
+    declarative (0.0.20)
+    digest-crc (0.6.5)
+      rake (>= 12.0.0, < 14.0.0)
+    domain_name (0.6.20240107)
+    dotenv (2.8.1)
+    emoji_regex (3.2.3)
+    excon (0.111.0)
+    faraday (1.10.3)
+      faraday-em_http (~> 1.0)
+      faraday-em_synchrony (~> 1.0)
+      faraday-excon (~> 1.1)
+      faraday-httpclient (~> 1.0)
+      faraday-multipart (~> 1.0)
+      faraday-net_http (~> 1.0)
+      faraday-net_http_persistent (~> 1.0)
+      faraday-patron (~> 1.0)
+      faraday-rack (~> 1.0)
+      faraday-retry (~> 1.0)
+      ruby2_keywords (>= 0.0.4)
+    faraday-cookie_jar (0.0.7)
+      faraday (>= 0.8.0)
+      http-cookie (~> 1.0.0)
+    faraday-em_http (1.0.0)
+    faraday-em_synchrony (1.0.0)
+    faraday-excon (1.1.0)
+    faraday-httpclient (1.0.1)
+    faraday-multipart (1.0.4)
+      multipart-post (~> 2)
+    faraday-net_http (1.0.2)
+    faraday-net_http_persistent (1.2.0)
+    faraday-patron (1.0.0)
+    faraday-rack (1.0.0)
+    faraday-retry (1.0.3)
+    faraday_middleware (1.2.0)
+      faraday (~> 1.0)
+    fastimage (2.3.1)
+    fastlane (2.222.0)
+      CFPropertyList (>= 2.3, < 4.0.0)
+      addressable (>= 2.8, < 3.0.0)
+      artifactory (~> 3.0)
+      aws-sdk-s3 (~> 1.0)
+      babosa (>= 1.0.3, < 2.0.0)
+      bundler (>= 1.12.0, < 3.0.0)
+      colored (~> 1.2)
+      commander (~> 4.6)
+      dotenv (>= 2.1.1, < 3.0.0)
+      emoji_regex (>= 0.1, < 4.0)
+      excon (>= 0.71.0, < 1.0.0)
+      faraday (~> 1.0)
+      faraday-cookie_jar (~> 0.0.6)
+      faraday_middleware (~> 1.0)
+      fastimage (>= 2.1.0, < 3.0.0)
+      gh_inspector (>= 1.1.2, < 2.0.0)
+      google-apis-androidpublisher_v3 (~> 0.3)
+      google-apis-playcustomapp_v1 (~> 0.1)
+      google-cloud-env (>= 1.6.0, < 2.0.0)
+      google-cloud-storage (~> 1.31)
+      highline (~> 2.0)
+      http-cookie (~> 1.0.5)
+      json (< 3.0.0)
+      jwt (>= 2.1.0, < 3)
+      mini_magick (>= 4.9.4, < 5.0.0)
+      multipart-post (>= 2.0.0, < 3.0.0)
+      naturally (~> 2.2)
+      optparse (>= 0.1.1, < 1.0.0)
+      plist (>= 3.1.0, < 4.0.0)
+      rubyzip (>= 2.0.0, < 3.0.0)
+      security (= 0.1.5)
+      simctl (~> 1.6.3)
+      terminal-notifier (>= 2.0.0, < 3.0.0)
+      terminal-table (~> 3)
+      tty-screen (>= 0.6.3, < 1.0.0)
+      tty-spinner (>= 0.8.0, < 1.0.0)
+      word_wrap (~> 1.0.0)
+      xcodeproj (>= 1.13.0, < 2.0.0)
+      xcpretty (~> 0.3.0)
+      xcpretty-travis-formatter (>= 0.0.3, < 2.0.0)
+    gh_inspector (1.1.3)
+    google-apis-androidpublisher_v3 (0.54.0)
+      google-apis-core (>= 0.11.0, < 2.a)
+    google-apis-core (0.11.3)
+      addressable (~> 2.5, >= 2.5.1)
+      googleauth (>= 0.16.2, < 2.a)
+      httpclient (>= 2.8.1, < 3.a)
+      mini_mime (~> 1.0)
+      representable (~> 3.0)
+      retriable (>= 2.0, < 4.a)
+      rexml
+    google-apis-iamcredentials_v1 (0.17.0)
+      google-apis-core (>= 0.11.0, < 2.a)
+    google-apis-playcustomapp_v1 (0.13.0)
+      google-apis-core (>= 0.11.0, < 2.a)
+    google-apis-storage_v1 (0.31.0)
+      google-apis-core (>= 0.11.0, < 2.a)
+    google-cloud-core (1.7.1)
+      google-cloud-env (>= 1.0, < 3.a)
+      google-cloud-errors (~> 1.0)
+    google-cloud-env (1.6.0)
+      faraday (>= 0.17.3, < 3.0)
+    google-cloud-errors (1.4.0)
+    google-cloud-storage (1.47.0)
+      addressable (~> 2.8)
+      digest-crc (~> 0.4)
+      google-apis-iamcredentials_v1 (~> 0.1)
+      google-apis-storage_v1 (~> 0.31.0)
+      google-cloud-core (~> 1.6)
+      googleauth (>= 0.16.2, < 2.a)
+      mini_mime (~> 1.0)
+    googleauth (1.8.1)
+      faraday (>= 0.17.3, < 3.a)
+      jwt (>= 1.4, < 3.0)
+      multi_json (~> 1.11)
+      os (>= 0.9, < 2.0)
+      signet (>= 0.16, < 2.a)
+    highline (2.0.3)
+    http-cookie (1.0.7)
+      domain_name (~> 0.5)
+    httpclient (2.8.3)
+    jmespath (1.6.2)
+    json (2.7.2)
+    jwt (2.8.2)
+      base64
+    mini_magick (4.13.2)
+    mini_mime (1.1.5)
+    multi_json (1.15.0)
+    multipart-post (2.4.1)
+    nanaimo (0.3.0)
+    naturally (2.2.1)
+    nkf (0.2.0)
+    optparse (0.5.0)
+    os (1.1.4)
+    plist (3.7.1)
+    public_suffix (6.0.1)
+    rake (13.2.1)
+    representable (3.2.0)
+      declarative (< 0.1.0)
+      trailblazer-option (>= 0.1.1, < 0.2.0)
+      uber (< 0.2.0)
+    retriable (3.1.2)
+    rexml (3.3.6)
+      strscan
+    rouge (2.0.7)
+    ruby2_keywords (0.0.5)
+    rubyzip (2.3.2)
+    security (0.1.5)
+    signet (0.19.0)
+      addressable (~> 2.8)
+      faraday (>= 0.17.5, < 3.a)
+      jwt (>= 1.5, < 3.0)
+      multi_json (~> 1.10)
+    simctl (1.6.10)
+      CFPropertyList
+      naturally
+    strscan (3.1.0)
+    terminal-notifier (2.0.0)
+    terminal-table (3.0.2)
+      unicode-display_width (>= 1.1.1, < 3)
+    trailblazer-option (0.1.2)
+    tty-cursor (0.7.1)
+    tty-screen (0.8.2)
+    tty-spinner (0.9.3)
+      tty-cursor (~> 0.7)
+    uber (0.1.0)
+    unicode-display_width (2.5.0)
+    word_wrap (1.0.0)
+    xcodeproj (1.25.0)
+      CFPropertyList (>= 2.3.3, < 4.0)
+      atomos (~> 0.1.3)
+      claide (>= 1.0.2, < 2.0)
+      colored2 (~> 3.1)
+      nanaimo (~> 0.3.0)
+      rexml (>= 3.3.2, < 4.0)
+    xcpretty (0.3.0)
+      rouge (~> 2.0.7)
+    xcpretty-travis-formatter (1.0.1)
+      xcpretty (~> 0.2, >= 0.0.7)
+
+PLATFORMS
+  ruby
+  x86_64-linux
+
+DEPENDENCIES
+  fastlane
+
+BUNDLED WITH
+   2.5.18

frontend/android/README.md

@@ -2,13 +2,12 @@

 ### Keystore setup
 ```bash
-keytool -genkey -v -keystore release.keystore -keyalg RSA -keysize 2048 -validity 10000 -alias release
+keytool -genkey -v -keystore release.keystore -keyalg RSA -keysize 2048 -validity 10000 -alias upload
 ```
-- This is required to store local credentials securely (not used for now).
-- But necesseary in order to restrict the particular api key to a particular app (through the sha1 of the associated keystore).
+- This is required to store local credentials securely and more importantly to sign the app for google play store distribution.


-### Building and secret credentials
+### Using secret credentials during build
 Following the guide under [https://developers.google.com/maps/flutter-package/config#android_1](https://developers.google.com/maps/flutter-package/config#android_1).
 - Add the following to `android/build.gradle`:
     ```gradle
@@ -36,13 +35,39 @@ Following the guide under [https://developers.google.com/maps/flutter-package/co
         android:value="${MAPS_API_KEY}" />
     ```

+### Signing the app
+Compared to the flutter template application, a few changes have to be made:
+- Added to `android/app/build.gradle`:
+    ```gradle
+        signingConfigs {
+            release {
+                keyAlias = secretProperties['keyAlias']
+                keyPassword = secretProperties['keyPassword']
+                storeFile = secretProperties['storeFile'] ? file(secretProperties['storeFile']) : null
+                storePassword = secretProperties['storePassword']
+            }
+        }
+    ```
+- Changed the `buildTypes` to use the `release` signing config:
+    ```gradle
+        buildTypes {
+            release {
+                signingConfig signingConfigs.release
+            }
+        }
+    ```
+    This makes use of the `secretProperties` defined previously:
+    ```gradle
+        secretPropertiesFile.withReader('UTF-8') { reader ->
+            secretProperties.load(reader)
+        }
+    ```
+

 ### Using the credentials in CI
-- Add the base64 encoded credentials to the repository secrets (e.g. `ANDROID_SECRETS`).
+- Add the secret files to the repository secrets (e.g. `ANDROID_SECRETS_PROPERTIES`).
+
+- temporarily write them back to files during the CI execution:
     ```bash
-    base64 -i android/secrets.properties
+    echo {{ secrets.ANDROID_SECRETS }} >> android/secrets.properties
     ```
-- Use the following in the CI script:
-    ```bash
-    echo {{ secrets.ANDROID_SECRETS }} | base64 -d > android/secrets.properties
-    ```

frontend/android/app/build.gradle

@@ -76,11 +76,18 @@ android {

     }

+    signingConfigs {
+        release {
+            keyAlias = secretProperties['keyAlias']
+            keyPassword = secretProperties['keyPassword']
+            storeFile = secretProperties['storeFile'] ? file(secretProperties['storeFile']) : null
+            storePassword = secretProperties['storePassword']
+        }
+    }
+
     buildTypes {
         release {
-            // TODO: Add your own signing config for the release build.
-            // Signing with the debug keys for now, so `flutter run --release` works.
-            signingConfig signingConfigs.debug
+            signingConfig = signingConfigs.release
         }
     }
 }

frontend/android/fastlane/Appfile

@@ -0,0 +1,2 @@
+json_key_file("google-key.json") # Path to the json secret file - Follow https://docs.fastlane.tools/actions/supply/#setup to get one
+package_name("com.anydev.anyway") # e.g. com.krausefx.app

frontend/android/fastlane/Fastfile

@@ -0,0 +1,45 @@
+# This file contains the fastlane.tools configuration
+# You can find the documentation at https://docs.fastlane.tools
+#
+# For a list of all available actions, check out
+#
+#     https://docs.fastlane.tools/actions
+#
+# For a list of all available plugins, check out
+#
+#     https://docs.fastlane.tools/plugins/available-plugins
+#
+
+# Uncomment the line if you want fastlane to automatically update itself
+# update_fastlane
+
+default_platform(:android)
+
+platform :android do
+  desc "Runs all the tests"
+  lane :test do
+    gradle(task: "test")
+  end
+
+  desc "Submit a new build to the closed testing lane"
+  lane :closed_testing do
+    gradle(
+      task: "bundle",
+      # flavor: "staging",
+      )
+
+    upload_to_play_store(
+      track: 'alpha',
+      skip_upload_apk: true,
+      skip_upload_changelogs: true,
+
+      )
+
+  end
+
+  desc "Deploy a new version to the Google Play"
+  lane :deploy do
+    gradle(task: "clean assembleRelease")
+    upload_to_play_store
+  end
+end

frontend/android/fastlane/README.md

@@ -0,0 +1,48 @@
+fastlane documentation
+----
+
+# Installation
+
+Make sure you have the latest version of the Xcode command line tools installed:
+
+```sh
+xcode-select --install
+```
+
+For _fastlane_ installation instructions, see [Installing _fastlane_](https://docs.fastlane.tools/#installing-fastlane)
+
+# Available Actions
+
+## Android
+
+### android test
+
+```sh
+[bundle exec] fastlane android test
+```
+
+Runs all the tests
+
+### android closed_testing
+
+```sh
+[bundle exec] fastlane android closed_testing
+```
+
+Submit a new build to the closed testing lane
+
+### android deploy
+
+```sh
+[bundle exec] fastlane android deploy
+```
+
+Deploy a new version to the Google Play
+
+----
+
+This README.md is auto-generated and will be re-generated every time [_fastlane_](https://fastlane.tools) is run.
+
+More information about _fastlane_ can be found on [fastlane.tools](https://fastlane.tools).
+
+The documentation of _fastlane_ can be found on [docs.fastlane.tools](https://docs.fastlane.tools).

frontend/android/fastlane/metadata/android/en-US/full_description.txt

@@ -0,0 +1,7 @@
+AnyWay - plan city trips your way
+
+AnyWay is a mobile application that helps users plan city trips. The app allows users to specify their preferences and constraints, and then generates a personalized itinerary for them. The planning follows some guiding principles:
+- **Personalization**:The user's preferences should be reflected in the choice of destinations.
+- **Efficiency**:The itinerary should be optimized for the user's constraints.
+- **Flexibility**: We aknowledge that tourism is a dynamic activity, and that users may want to change their plans on the go.
+- **Discoverability**: Tourism is an inherently exploratory activity. Once a rough itinerary is generated, detours and spontaneous decisions should be encouraged.

frontend/android/fastlane/metadata/android/en-US/short_description.txt

@@ -0,0 +1 @@
+AnyWay - plan city trips your way!

frontend/android/fastlane/metadata/android/en-US/title.txt

@@ -0,0 +1 @@
+AnyWay

frontend/android/fastlane/report.xml

@@ -0,0 +1,23 @@
+<?xml version="1.0" encoding="UTF-8"?>
+<testsuites>
+  <testsuite name="fastlane.lanes">
+
+
+
+
+      <testcase classname="fastlane.lanes" name="0: default_platform" time="0.000594355">
+
+      </testcase>
+
+
+      <testcase classname="fastlane.lanes" name="1: bundle" time="11.355126485">
+
+      </testcase>
+
+
+      <testcase classname="fastlane.lanes" name="2: upload_to_play_store" time="63.414149183">
+
+      </testcase>
+
+  </testsuite>
+</testsuites>

frontend/pubspec.lock

@@ -705,10 +705,10 @@ packages:
     dependency: transitive
     description:
       name: vm_service
-      sha256: f652077d0bdf60abe4c1f6377448e8655008eef28f128bc023f7b5e8dfeb48fc
+      sha256: "5c5f338a667b4c644744b661f309fb8080bb94b18a7e91ef1dbd343bed00ed6d"
       url: "https://pub.dev"
     source: hosted
-    version: "14.2.4"
+    version: "14.2.5"
   web:
     dependency: transitive
     description:
